Hydro miners rely entirely on the effectiveness and continuous operation of the liquid cooling system. Cheap “water cooling cabinets” offered by cryptominer resellers are risky choice and may ruin your miners. This is precisely why we developed DCX HYDRO100 CDU System. It features dual high-quality smart pumps that can be controlled remotely installed in 42U datacenter rack frame. Pumps can operate in redundancy mode or at full capacity transferring over 160kW of heat. System is fully universal accommodating either 10-12 MicroBt M56S++ Whatsminers or 20 or even 30 Bitmain Hydro miners or even standard servers, which gives users great flexibility.
As part of our package, we offer dry coolers, remote installation assistance, appropriate additives, and more. What sets our HYDRO100 rack system apart is its potential for sustainable operation with built in heat exchanger, enabling the reuse of generated heat.
Capacity
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus amet
Performance
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus amet
Sustainability
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus amet
Energy Efficiency
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus amet
Overview
Hydro miners rely entirely on the effectiveness and continuous operation of the liquid cooling system. Cheap “water cooling cabinets” offered by cryptominer resellers are risky choice and may ruin your miners. This is precisely why we developed DCX HYDRO100 CDU System. It features dual high-quality smart pumps that can be controlled remotely installed in 42U datacenter rack frame. Pumps can operate in redundancy mode or at full capacity transferring over 160kW of heat. System is fully universal accommodating either 10-12 MicroBt M56S++ Whatsminers or 20 or even 30 Bitmain Hydro miners or even standard servers, which gives users great flexibility.
As part of our package, we offer dry coolers, remote installation assistance, appropriate additives, and more. What sets our HYDRO100 rack system apart is its potential for sustainable operation with built in heat exchanger, enabling the reuse of generated heat.
Main Features:
- Hydro rack system with built-in redundant CDU and optional heat exchange system.
- Compact dimensions of 42U 600x800mm rack
- Universal system to host 10-12 x M53S++ miners or 20-30 Bitmain Hydro miners.
- Continuous all-year-round operation in performance mode of M53S++ up to 9.4 kW in the Middle East or Texas with ambient temp. Up to 50C / 122F
- Heat reuse option with built-in 40-100kW brazed plate heat exchanger.
- Safe N+1 redundant smart pump system providing high availability for liquid-cooled miners. No risk of downtime ever.
- Complete remote monitoring and control of pumps and inlet-outlet temperatures.
- Backed up with a full vendor warranty and DCX support.
Features
- Hydro CDU System, smart pumps and heat exchanger
- Compact 42U 600x800mm rack
- Hosts 10-12 x M53S++ miners with up to 9.4kW
| Ninja Column 1 | Ninja Column 2 | Ninja Column 3 | Ninja Column 4 | Ninja Column 5 | Ninja Column 6 | Ninja Column 7 | Ninja Column 8 | Ninja Column 9 | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| DCX HYDRO 200 RACK | Whatsminer M53 / M63 series | Bitmain S19 / S21 Hydro | |||||||||||||
| Miner Capacity | 22 | 36 | |||||||||||||
| Heat Transfer Capacity [kW] | 211 | 75 | |||||||||||||
| Max Power / Miner [kW] | 9.6 | 7.4 | |||||||||||||
| CDU Operating Power [W] | Individually selected pump | Individually selected pump | |||||||||||||
| Primary Loop Temperatures | Supply 20-50°C | Return 40-70°C | ||||||||||||||
| Ambient Operation Temperature | -30°C~50°C | -22°F~122°F | ||||||||||||||
| Ambient Humidity | 5-95% RH | ||||||||||||||
| PDU Input voltage | 3P custom 380-440V 50/60HZ 400A | ||||||||||||||
| PDU Socket | 22 x SA2-30 380-400V 20A or 2 x PDU with 36 PA 45 50A | ||||||||||||||
| PDU Output voltage | 3P custom / standard 380-440V 50/60HZ | 1P 220V or 230V 50/60H | ||||||||||||||
| Dimensions (LxWxH) [mm] | 800x1200x2000 | ||||||||||||||
| Weight [kg] | 220 kg | ||||||||||||||
| Pipe connection diameters | DN60 | ||||||||||||||
| BPHX / Heat Reuse Capacity | 99.99 % | ||||||||||||||
| Certification | CE | UL & ETL at request | ||||||||||||||
| Primary Loop Monitoring & Control | Remote monitoring & control: Flow, Temperatures | ||||||||||||||
| Rack Monitoring | Remote monitoring: Temperature & Humidity Monitoring | ||||||||||||||
| PDU (if included) | Remote monitoring & control: Power, Voltage, Alarms, Reset | ||||||||||||||
| Heat Reuse | Facility connection providing return temp 20-50°C | ||||||||||||||
| Heat Rejection to Dry Cooler | DCX Immersion Optimized Dry cooler | ||||||||||||||
Features
- Enterprise class system & controls with full redundancy
- Complete loop separation and condensation control
- From 300kw to 1.2MW per single CDU
- From 6 to 28 server racks per single CDU
System Build
DCX HYDRO200 Rack
Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris nisi ut aliquip ex ea commodo consequat. Duis aute irure dolor in reprehenderit in voluptate velit esse cillum dolore eu fugiat nulla pariatur. Excepteur sint occaecat cupidatat non proident, sunt in culpa qui officia deserunt mollit anim id est laborum.
Lorem ipsum dolor sit amet enim. Etiam ullamcorper. Suspendisse a pellentesque dui, non felis. Maecenas malesuada elit lectus felis, malesuada ultricies. Curabitur et ligula. Ut molestie a, ultricies porta urna. Vestibulum commodo volutpat a, convallis ac, laoreet enim. Phasellus fermentum in, dolor. Pellentesque facilisis. Nulla imperdiet sit amet magna. Vestibulum dapibus, mauris nec malesuada fames ac turpis velit, rhoncus eu, luctus et interdum adipiscing wisi. Aliquam erat ac ipsum. Integer aliquam purus. Quisque lorem tortor fringilla sed, vestibulum id, eleifend justo vel bibendum sapien massa ac turpis faucibus orci luctus non, consectetuer lobortis quis, varius in, purus. Integer ultrices posuere cubilia Curae, Nulla ipsum dolor lacus, suscipit adipiscing. Cum sociis natoque penatibus et ultrices volutpat.
Steel cover to prevent contamination, with spill prevention components.
All-steel enclosure big enough to house up to 400kg of dielectric fluid and miners. Building block for the rack or scale-out container installations. Enables high-temperature mining for the best heat transfer parameters. No more plastic boxes that can crack, leak or melt anytime, no more problems with temperature limits, no more problems with grounding.
L shaped frames to mount external components – switchgear, monitoring systems or PSUs. Placement of PSU outside of the immersion bath requires more retrofitting for the miners, but enables even bigger density and higher temperature for better heat exchange.
IP40 switchgear box for 10-12 3-4kW miners. Contains: 10-12 x overcurrent protection, circuit breaker, cable fittings, terminal blocks, cabling. We use top class Schneider, Eaton, Legrand or Siemens components.
Miner stack area. Sized carefully taking into account various miner types. Allows for flexible placement of different miners. Including: 15x Whatsminer M20/M30/M31 12x Whatsminer M21 8x Antminer S17+ / S17e / T17+ 8x Antminer S19 / S19PRO / T19 10x Innosilicon A10 PRO / A9 / A6 23x Innosilicon A10 (500M) 18x Antminer S9SE / S9K 20x Antminer S9I / S9J 8-16 x Mining rig with up to 12 GPU each 6-7x Hummer H1 Miner 5x Antminer K5 CKB Eaglesong 8-16 GPU rigs with 12GPU each (96-192GPUS)
ThermaSafe R™ Dielectric Engineered Fluid Best priced, 2 times better than recognized Bitcool BC-888 ASIC miner dielectric coolant. Dielectric, odorless, non-toxic, non-allergenic, long-life, eco friendly and safe HTF (Heat Transfer Fluid). Designed specifically for crypto mining operations, compatible with most ASIC, GPU and electronic equipment.
Filling kit. Flexible miners require more effort on fluid control. We want all the fluid to go through the miners not around. To enable a higher pressure drop around the miners we deliver filling kits which direct the fluid through the miners.
Get in Touch
We will advise, guide and support – the ideas are always free of charge!
Get your custom solution:
We need basic information to design custom liquid cooling system:
-
Quantity and general specification and dimensions of servers, ICT systems or other to be cooled components, along with power allocation per device or rack.
-
Brief overview of your project along with your main objective: better performance, water savings, energy efficiency, heat reuse, higher density?
-
Preferred liquid cooling technology: direct chip – coldplate system or immersion solution? Planned heat rejection or heat recovery strategy.
-
Country & city nearby planed location for climate data, heat transfer performance & shipping cost estimate.
